Home > Rene 41 Sheets and Plates
Adarsh Nickel Alloys stands out as a leading manufacturer and supplier based in Delhi, specializing in top-notch Rene 41 Sheets and Plates tailored for aerospace, power generation, and high-temperature industrial uses. The company prides itself on precision manufacturing, rigorous quality control, and strict adherence to international standards, ensuring that their sheets and plates boast consistent properties, exceptional strength, and a flawless surface finish. With state-of-the-art facilities and a wealth of technical expertise, Adarsh Nickel Alloys offers Rene 41 products in customized sizes and specifications, guaranteeing timely delivery and competitive pricing. They serve a variety of sectors, including aerospace, gas turbines, nuclear, and research industries, and are well-regarded for their durable, high-performance nickel-based superalloy solutions that excel in extreme conditions.
Rene 41 Sheets and Plates are crafted from nickel-based superalloys that include chromium, cobalt, molybdenum, titanium, aluminum, and a few trace elements. This unique blend gives them remarkable high-temperature strength, oxidation resistance, and creep resistance. On the mechanical side, Rene 41 showcases impressive tensile and yield strength, outstanding fatigue resistance, and excellent toughness, even when exposed to elevated temperatures. It also maintains its dimensional stability and structural integrity during thermal cycling and in harsh environments. These characteristics make Rene 41 sheets and plates perfect for components that face extreme mechanical stress and high-temperature conditions.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Rene 41 Sheets and Plates find extensive use in industries that demand high strength and thermal resistance. They are frequently utilized in aerospace for turbine blades, rocket motor cases, and various airframe components. In the power generation sector, Rene 41 is essential for gas turbine components and high-temperature industrial equipment. Additionally, nuclear and research facilities rely on these sheets and plates for reactor components and experimental setups, thanks to their ability to withstand the rigors of extreme conditions.
