Adarsh Nickel Alloys has earned a solid reputation as a reliable manufacturer and supplier based in Delhi, focusing on top-notch **Inconel 625 Stud Bolts** designed for tough industrial and high-temperature settings. With a commitment to precision engineering and strict quality control, the company adheres to international standards, delivering stud bolts that boast remarkable corrosion resistance, mechanical strength, and precise dimensions. By using premium-grade Inconel 625 alloy and cutting-edge manufacturing techniques, Adarsh Nickel Alloys guarantees dependable performance even in extreme conditions. Catering to clients throughout India and beyond, they offer tailored solutions, prompt delivery, and competitive pricing, making them a go-to choice for industries in need of robust and high-performance Inconel 625 stud bolts.
Inconel 625 Stud Bolts are primarily made up of nickel (at least 58%), chromium (20–23%), molybdenum (8–10%), and niobium, along with trace amounts of iron, manganese, and silicon. This unique blend provides exceptional resistance to corrosion, oxidation, and pitting, especially in harsh chemical and marine environments. On the mechanical side, these stud bolts showcase impressive tensile and yield strength, outstanding fatigue resistance, and good ductility. They maintain stable mechanical properties even under high temperatures and stress, effectively resisting stress corrosion cracking, which ensures reliable performance in critical industrial, chemical, and offshore applications.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Stud Bolts in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 Stud Bolts find extensive use in industries that demand high strength, corrosion resistance, and durability in extreme conditions. They are commonly utilized in chemical processing plants, petrochemical equipment, and the oil and gas sector. Additionally, these stud bolts are widely employed in marine and offshore structures, heat exchangers, and power generation systems that are exposed to corrosive environments.
