Adarsh Nickel Alloys, based in Delhi, stands out as a top manufacturer and supplier of high-quality Inconel 601 Stud Bolts. Renowned for their remarkable strength and outstanding resistance to high-temperature oxidation and corrosion, these stud bolts are designed to excel in the toughest industrial settings. Adarsh Nickel Alloys guarantees that each stud bolt is crafted with precision, adhering to international quality standards, which ensures durability, reliability, and a long lifespan. With options for custom sizes and quick delivery, the company has earned a reputation as a trusted partner for industries in need of high-performance Inconel 601 Stud Bolts for critical applications in the chemical, power, and aerospace sectors.
Inconel 601 Stud Bolts are primarily made up of nickel (about 58%) and chromium (21–25%), along with trace amounts of iron, manganese, silicon, and carbon. This unique blend gives them exceptional resistance to oxidation, corrosion, and high-temperature degradation. In terms of mechanical properties, these stud bolts boast a tensile strength ranging from 75–90 ksi, a yield strength of 30–55 ksi, and an elongation of 40–50%, ensuring they can withstand extreme conditions. They maintain their structural integrity at temperatures reaching up to 2200°F (1204°C) and resist carburization and thermal fatigue, making them a reliable choice for high-temperature, high-stress industrial applications.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Stud Bolts in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 Stud Bolts find extensive use in industries where high-temperature strength and corrosion resistance are essential. They are frequently used in chemical processing plants, gas turbines, furnace construction, and heat treatment equipment. In the aerospace sector, these bolts are crucial for exhaust systems and high-temperature assemblies, while in power generation, they are perfect for boiler and turbine components. Moreover, they are well-suited for petrochemical, marine, and nuclear applications, where they face exposure to oxidizing environments and extreme conditions.
