Adarsh Nickel Alloys stands out as a reliable manufacturer and supplier based in Delhi, specializing in high-quality Hastelloy manifold valves that are engineered for exceptional performance in tough, corrosive industrial settings. Crafted from top-notch Hastelloy alloys and utilizing precision engineering methods, these valves ensure remarkable dimensional accuracy, robust mechanical strength, and impressive long-term durability. Adarsh Nickel Alloys offers Hastelloy manifold valves in a variety of sizes, pressure ratings, and tailored specifications to cater to a wide range of industrial needs. With a strong commitment to quality control and compliance with international standards, the company provides dependable valve solutions that are perfect for high-temperature, high-pressure, and chemically aggressive environments.
These Hastelloy manifold valves are made from nickel-based alloys enriched with chromium, molybdenum, and iron, which grant them outstanding resistance to corrosion and mechanical stress. This unique composition helps them withstand pitting, crevice corrosion, stress corrosion cracking, and chemical attacks in both oxidizing and reducing conditions. On the mechanical side, Hastelloy manifold valves boast high tensile and yield strength, excellent toughness, good ductility, and reliable creep resistance even at elevated temperatures. They maintain their shape and functionality under intense thermal and mechanical stress.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Needle Valve in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy manifold valves find extensive applications in industries such as chemical processing, oil and gas, petrochemical, power generation, and marine. They are perfect for managing and directing the flow of aggressive chemicals, high-temperature fluids, and corrosive substances in process systems, reactors, heat exchangers, and pressure vessels. Thanks to their superior corrosion resistance, mechanical strength, and durability, these valves ensure reliable operation, a long service life, and minimal maintenance, making them vital components in critical industrial applications where safety and efficiency are key.
