Adarsh Nickel Alloys is a trusted manufacturer and supplier of high-performance Hastelloy Ball Valves in Delhi, designed for precise flow control in highly corrosive and high-temperature environments. These valves are manufactured using premium Hastelloy alloys and advanced engineering techniques to ensure smooth operation, tight shut-off, and long service life. Known for their exceptional resistance to corrosion, pitting, and stress corrosion cracking, Hastelloy ball valves from Adarsh Nickel Alloys deliver reliable performance in the most demanding industrial conditions.
Hastelloy Ball Valves are typically manufactured from nickel-based alloys containing significant amounts of chromium, molybdenum, and iron, depending on the grade. This composition provides excellent resistance to acids, chlorides, and aggressive chemicals. Mechanically, Hastelloy offers high tensile and yield strength, outstanding toughness, and good ductility. These alloys retain their mechanical integrity at elevated temperatures and under pressure, ensuring reliable valve operation with minimal wear and long-term structural stability.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Ball Valve in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy Ball Valves supplied by Adarsh Nickel Alloys are widely used in chemical processing plants, petrochemical industries, and oil and gas operations. They are ideal for controlling the flow of corrosive fluids, acids, and high-temperature media. These valves are also used in pharmaceutical manufacturing, pulp and paper processing, pollution control systems, and offshore applications. Their superior corrosion resistance, tight sealing capability, and durability make them a preferred choice for critical flow control applications requiring safety, efficiency, and long service life.
