Incoloy 825 is a nickel-iron-chromium alloy that’s enhanced with molybdenum, copper, and titanium, giving it impressive resistance to acids and corrosive environments. This alloy boasts good tensile and yield strength, along with excellent ductility and resistance to stress corrosion cracking. Incoloy 825 forgings maintain their mechanical integrity even at elevated temperatures and show good toughness and fatigue strength. Additionally, the alloy is known for its favorable weldability and machinability, making it ideal for crafting complex forged components designed for high-performance industrial applications.
| Specifications | ASTM B564, ASME SB564 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Incoloy 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Forgings in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 825 Forgings are extensively utilized in industries that demand robust, corrosion-resistant components capable of withstanding harsh operating conditions. Typical applications include valves, flanges, shafts, and fittings found in chemical processing and acid handling systems. In the oil and gas industry, these forgings are essential for offshore platforms, pipelines, and pressure-containing components. They also play a vital role in power generation, marine engineering, and pollution control equipment. Thanks to their outstanding resistance to aggressive chemicals, high temperatures, and mechanical stress, Incoloy 825 forgings are a go-to choice for many demanding applications.
