Adarsh Nickel Alloys is a well-respected manufacturer and supplier based in Delhi, specializing in high-quality Inconel pipe fittings designed for critical and demanding industrial applications. These fittings are crafted using cutting-edge production techniques and top-notch raw materials, ensuring they deliver outstanding strength, precise dimensions, and long-lasting reliability. Adarsh Nickel Alloys offers a diverse selection of Inconel pipe fittings in various types, sizes, pressure classes, and custom specifications to cater to a wide range of project requirements. With rigorous quality checks and a commitment to international standards, the company guarantees products that perform reliably even in extreme temperatures, high pressures, and corrosive environments.
Inconel pipe fittings are constructed from nickel-chromium-based superalloys, often enhanced with elements like iron, molybdenum, and niobium to boost their strength and resistance to corrosion. This unique chemical makeup provides excellent protection against oxidation, pitting, and chemical attacks. On the mechanical side, Inconel pipe fittings showcase high tensile and yield strength, impressive toughness, and exceptional creep resistance at elevated temperatures. They maintain their mechanical integrity and stability, even when faced with severe thermal and mechanical stress.
| Specification | ASTM B366, ASTM SB 366, ASTM B564, ASME SB564 |
| Grade | Inconel 600 (UNS N06600, Alloy 600, 2.4816), Inconel 601 (UNS N06601, Alloy 601, 2.4851), Inconel 625 (UNS N06625, Alloy 625, 2.4856), Inconel 800 (UNS N08800, Alloy 800) |
| Type | Seamless / Welded / Fabricated |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Range | 1/2”NB to 24″NB in Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| Inconel Grade | C | Mg | S | P | Cr | Si | Mo | Ni | Co | Cu | Al | Ti | Ni | I | B |
| Inconel 600 | 0.15 | 1.00 | 0.015 | – | 14.0–17.0 | 0.50 | – | – | – | 0.50 | – | – | 72.0max | 6.0–10.0 | – |
| Inconel 617 | 0.15 | 0.50 | 0.015 | 0.015 | 20.0–24.0 | 0.50 | 8.0–10.0 | – | 10.0–15.0 | 0.50 | 0.8–1.50 | 0.60 | 44.2–56.0 | 3.00max | 0.006 |
| Inconel 625 | 0.10 | 0.50 | 0.015 | 0.015 | 20.0–23.0 | 0.50 | 8.0–10.0 | 3.15–4.15 | 1.00 | – | 0.40 | 0.40 | 58.0max | 5.00max | – |
| Inconel 690 | 0.019 | 0.35 | 0.003 | – | 30.0max | 0.35 | – | – | – | 0.01 | 0.02 | – | 59.5max | 9.20max | – |
| Inconel 718 | 0.08 | 0.35 | 0.015 | 0.015 | 17.0–21.0 | 0.35 | 2.8–3.3 | 4.75–5.5 | 1.00 | 0.2–0.8 | 0.65–1.15 | 0.30 | 50.0–55.0 | balance | 0.006 |
| Inconel X-750 | 0.08 | 1.00 | 0.01 | – | 14.0–17.0 | 0.50 | – | 0.7–1.2 | 1.00 | 0.50 | 0.4–1.0 | 2.25–2.75 | 70.0max | 5.0–9.0 | – |
| CONDITION | TENSILE STRENGTH | YEILD STRENGTH | ELOGNATION |
|---|---|---|---|
| ANNEALED, UPTO 4″ (102 MM) | 120 (827) | 60 (414) | 30 |
| ANNEALED, OVER 4″ (102 MM) – 10″(254 MM) | 110 (758) | 50 (345) | 25 |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Pipe Fittings in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These fittings find extensive use across various industries, including oil and gas, chemical processing, power generation, aerospace, and marine sectors. They are particularly suited for piping systems that handle high-temperature fluids, corrosive chemicals, and high-pressure media. Common applications include heat exchangers, reactors, refineries, and offshore installations. Thanks to their remarkable durability, corrosion resistance, and strength, Inconel pipe fittings ensure leak-free connections, a longer service life, and enhanced operational safety in challenging industrial settings.
