Adarsh Nickel Alloys is a reliable manufacturer and supplier of premium Incoloy 800, 800H, and 800HT Stud Bolts in Delhi, catering to industries that demand strength, stability, and resistance at elevated temperatures. These stud bolts are manufactured using high-grade alloy materials and precision machining to ensure accurate threading, excellent load-bearing capacity, and long service life. Known for their outstanding performance in high-temperature and corrosive environments, Incoloy 800 series stud bolts from Adarsh Nickel Alloys provide secure fastening solutions for critical industrial assemblies.
Incoloy 800 / 800H / 800HT Stud Bolts are primarily composed of nickel, iron, and chromium, offering excellent resistance to oxidation and carburization. Variants 800H and 800HT feature controlled carbon and aluminum-titanium content for improved creep and rupture strength at high temperatures. Mechanically, these alloys provide good tensile and yield strength, high ductility, and excellent resistance to thermal fatigue. Their stable mechanical properties make them suitable for long-term service in extreme heat and pressure conditions.
| Stud Bolt size | M02 to M33, Custom Sizes |
|---|---|
| Stud Bolts Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard of Stud Bolts | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form of Stud Bolts | Hex, Threading, Square, Round as per Gauge Etc. |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin, etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Popular Types of Stud Bolt | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate of Stud Bolts | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Stud Bolts Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Stud Bolts finishing | Coatings & Finishes : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide, |
| Grade | C | Mn | Si | S | Cr | Fe | Ni |
| Incoloy 800 | 0.1 max | 1.5 max | 1.0 max | 0.015max | 19.0 – 23.0 | 39.5 min | 30.0 – 35.0 |
| Incoloy 800H | 0.05 – 0.1 | 1.5 max | 1.0 max | 0.015 max | 19.0 – 23.0 | 39.5 min | 30.0 – 35.0 |
| Incoloy 800HT | 0.06 – 0.1 | 1.5 max | 1.0 max | 0.015 max | 19.0 – 23.0 | 39.5 min | 30.0 – 35.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Stud Bolts in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 800 series stud bolts supplied by Adarsh Nickel Alloys are widely used in heat exchangers, pressure vessels, furnace components, and petrochemical equipment. They are ideal for fastening applications in power plants, refineries, chemical processing units, and thermal processing systems. These stud bolts are also commonly used in flanges, valves, and high-temperature piping systems where mechanical integrity is critical. Their ability to maintain strength and resist oxidation under continuous high heat makes them a preferred choice for demanding industrial applications.
