Adarsh Nickel Alloys stands out as a reliable manufacturer and supplier of Titanium Grade 5 Tube Fittings in Delhi, providing precision-engineered solutions for high-performance piping systems. Crafted from top-notch Ti-6Al-4V alloy and utilizing cutting-edge machining techniques, these fittings offer remarkable strength, corrosion resistance, and long-lasting reliability. With a commitment to strict quality control, dimensional accuracy, and adherence to international standards, Adarsh Nickel Alloys serves various industries, including aerospace, chemical processing, marine, oil & gas, and power generation, delivering titanium tube fittings that excel in extreme pressure, temperature, and corrosive conditions.
Titanium Grade 5, or Ti-6Al-4V, is made up of titanium combined with about 6% aluminum and 4% vanadium. This unique blend strikes a perfect balance between high strength, lightweight characteristics, and corrosion resistance. In terms of mechanics, Titanium Grade 5 Tube Fittings showcase impressive tensile and yield strength, exceptional fatigue resistance, and solid fracture toughness. They maintain their mechanical integrity across a broad temperature range and offer good weldability, making them ideal for high-pressure and high-stress piping applications.
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6000 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Adarsh Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 5 Tube Fittings in Delhi, India, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the India, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Grade 5 Tube Fittings find their place in a variety of applications that demand high strength, corrosion resistance, and reduced weight. They are frequently used in aerospace hydraulic and fuel systems, chemical processing pipelines, and marine and offshore setups. In the oil & gas sector, these fittings thrive in high-pressure and corrosive environments. Additionally, they play a vital role in power generation and automotive performance systems, showcasing their versatility and reliability in challenging conditions.
